Overview:
Product Overview
The Overland-Tandberg LTO-8 tape drive technology is the newest LTO-generation and follows the roadmap of the LTO consortium, which now includes 12 generations.
The uncompressed capacity has doubled to 12TB compared to the predecessor LTO-7. The compressed transfer rate remains the same and amounts to 2.7TB/h. LTO-7 is the optimal solution for capacity-hungry, performance-driven applications like in the media and entertainment industry, in imaging applications, in medical environments or for the collection of scientific data. The LTO-7 tape drive supports LTFS, WORM and AES 256-bit hardware encryption providing maximum protection for data stored off-site or in transit. LTO-8 is read/write compatible with LTO-7.
Features
- Capacity: 12TB / 30TB (native/compressed*)
- Performance up to 2.7 TB/h (compressed*)
- Low cost of ownership and low media cost
- Enterprise features and performance in a small form factor
- Future proof with 12-generation roadmap
- Data speed matching reduces mechanical wear and extends tape life
- Proven reliability MTBF of 250,000 hrs. at 100% duty cycle
- LTFS, WORM and AES 256-bit encryption
- 30 year archival life
- 3 years Advanced Replacement Service warranty
LTO-7 Type M
LTO-7 type M media are LTO-7 media, which are initialized in a LTO-8 drive. In addition, dedicated barcode labels will be used to mark these media in an automation environment. LTO-7 type M media provide a capacity of 9TB, which is a perfect choice for customers who do not need the total capacity of a LTO-8 media.
* Assumes compression ratio of 2:1 on LTO-4/5 and 2.5:1 on LTO-6,7 and 8
Specifications:
| Capacity (native/compressed) | 12TB / 30TB* |
| Transfer Rate (native/compressed) | 300 MB/s / 750 MB/s* |
| Dynamic Speed Matching | 112-300MB/s |
| Memory Buffer Size | 1GB |
| Data Access Speed | 50 sec. |
| Data Compression | 16KB (2.5:1) |
| Encryption | AES 256-bit |
| LTFS | Yes |
| Recording format | LTO Ultrium 7 |
| Interface | 6GB SAS/SFF 8088 |
| Reliability | |
| MTBF Hours (100% duty cycle) | 250,000 hours @ 100% duty cycle |
| Head Life | 100,000 tape running hours |
| Hard Error Rate | 1 x 10(-19) bits |
| Environmental Specifications | |
| Temperature (Operating) | 50° - 100°F (10°C - 38°C) |
| Temperature (Non-operating) | -40° – 151°F (-5°C - 65°C) |
| Relative Humidity (Operating) | 20 – 80% (non-condensing) |
| Relative Humidity (Non-operating) | 10 – 95% (non-condensing) |
| Power Requirements | |
| Idle | 4 W |
| Typical | 30 W |
| Maximum | 42 W |
| Power Supply/ Required (int) | 5V DC, 3.7A, 12 V, 0.9A |
| Certification | CSA Certification to C22.2, No. 60950 (cCSAus), TUV EN60950 (IEC 60950), CE Declaration of Conformity, FCC 47 CFR Parts 15, NOM, VCCI. C-TICK, RRL, BSMI, GOSH CB Certificate and Report (IEC 60950) |
| Warranty | 3-years Advance Replacement Service Warranty** |
| Dimensions | |
| Physical Internal / External (HxWxD) | 1.7 in. x 5.8 in. x 8.3 in.(43.2mm x 147.3mm x 210.8mm) / 2.3 in. x 8.4 in. x 13.1 in. (58.4mm x 213.4mm x 332.7mm) |
| Weight | |
| Weight Out of box, Internal | 3.7 lbs. (1.7 kg) |
| Weight Out of box, External | 9.4 lbs. (4.3 kg) |
* Assumes compression ratio 2:1 on LTO-2/3/4/5 & 2.5:1 on LTO-6/7/8
** Availability dependent on location
Benefits:
- Low Storage Cost
LTO provides the lowest cost per GB of any medium - Business Efficiency
Manage less data, reduce downtime and speed up applications - Ease of Use
Simplify data migration with LTFS - Long-Term Archiving
30-year archival life - Security
Protect your data from unauthorized access - Superior Warranty
3-year Advance Replacement Service Warranty*
* Availability dependent on location
Documentation:
Download the Overland Tandberg Data LTO-8 Half Height Tape Drive Datasheet (PDF).
