Tandberg LTO-5 Half Height Tape Drive
Reliable, High-capacity Tape Drives

Tandberg LTO-3 Half Height Tape Drive

Tandberg LTO Tape Drives
Tandberg LTO-5 Half Height Tape Drive
Tandberg LTO-5 HH - Internal bare drive, black, SAS
#3518-LTO
List Price: $1,599.00
Our Price: $1,338.00
Tandberg LTO-5 HH - Internal drive kit, black, SAS
#3519-LTO
List Price: $1,599.00
Our Price: $1,338.00
Tandberg 1U Rackmount SAS
Tandberg 1U Rackmount SAS, supports up to 2 LTO HH SAS drives.
#3512-LTO
List Price: $649.00
Our Price: $529.00

Click here to jump to more pricing!

Overview:

The Tandberg Data's LTO-5 half-height (HH) tape drive brings enterprise-level capacity and performance to small and medium businesses at an affordable price. The Tandberg Data LTO-5 HH drive is able to store up to 3.0TB* of data on a single cartridge offering the lowest storage cost per gigabyte of any medium. Tandberg Data LTO-5 HH tape drives offer industry leading performance up to 1 TB/hr* (280 MB/sec), reducing backup and restore times to a minimum.

  • Capacity: 1.5 / 3.0TB (native/compressed)
  • Performance up to 1.0 TB/hr (compressed)
  • Low cost of ownership and low media cost
  • Enterprise features and performance in a small form factor
  • Future proof with 8-generation roadmap
  • Data speed matching, reduces mechanical wear and extends tape life
  • Proven reliability MTBF of 250,000 hrs at 100% duty cycle
  • Low power consumption: 6.9 W (sleeping mode) and 20 W (operating mode)
  • WORM and Encryption (AES 256-bit)
  • 30 year archival life
  • 3 years Advanced Replacement Service warranty

Tandberg Data manufactures an array of LTO-5 HH models including internal, external and rackmount configurations, with a choice SAS or FC connectivity. Tandberg Data is the only manufacturer to offer a LTO-5 HH FC external tape drive. All Tandberg Data LTO-5 tape drives support LTFS (Linear Tape File System). LTFS simplifies archiving tasks and is fast becoming the standard recording format within the video and entertainment industry.

Tandberg Data is the sole manufacturer of LTO-5/6 HH fibre channel external (table-top) tape drives, when used in conjunction with a FC to Thunderbolt bridge (Promise or Atto) the LTO-5 tape drives provides customers, especially Mac users, with a unique and high performance backup and archiving solution to simplify digital workflow and archiving needs.

LTO tape technology makes it easy for users to standardize on a tape technology that meets today's data capacity requirements and ensures futures growth potential. LTO's eight-generation roadmap, with four generations available today makes it a clear choice for small to medium businesses.

Turnkey Solution

The Tandberg LTO-5 HH ships with Symantec's Backup Exec QuickStart software, embedded media management for intelligent diagnostics and tape alerts, and comes with 3 years warranty and support. (Backup Exec QuickStart software is only supplied with kitted products)

Media Compatibility

The Tandberg LTO-5 HH is compatible with industry standard, multi-sourced LTO media. To achieve the best reliability, Tandberg LTO branded and qualified data cartridges are recommended.

Specifications:

Tandberg LTO-5 Half Height Specifications:
Capacity (native) 1500 GB
Capacity (comp.) 3000 GB
Transfer Rate (native) 140 MB/s
Transfer Rate (comp.) 280 MB/s
Dynamic Speed Matching 47–140 MB/s / 94–280 MB/s*
Memory Buffer Size 256MB
Data Access Speed 52 sec
Data Compression 1KB (2:1)
Encryption AES 256-bit
LTFS Yes (2 partitions)
Recording Format LTO Ultrium 5, LTO Ultrium 4, LTO Ultrium 3 (read only)
Reliability
MTBF Hours (100% duty cycle) 250,000 hours @ 100% duty cycle
Head Life 60,000 tape running hours
Hard Error Rate 1 x 10(-17) bits
Environmental Specifications
Temperature (Operating)‡ 50° – 95°F
Temperature (Non-operating) 40° – 151°F
Relative Humidity (Operating) 20 – 80% (non-condensing)
Relative Humidity (Non-operating) 10 – 95% (non-condensing)
Power Requirements
Idle 7 W
Typical 20 W
Maximum 33 W
Power Supply/ Required (int) 5V DC, 2.5A, 12 V, 0.7A
Certification CSA Certification to C22.2, No. 60950 (cCSAus), TUV EN60950 (IEC 60950), CE Declaration of Conformity, FCC 47 CFR Parts 15, NOM, VCCI. C-TICK, RRL, BSMI, GOSH CB Certificate and Report (IEC 60950)
Warranty 3-years Advance Replacement Service Warranty**
Dimensions
Physical Internal / External (HxWxD) 1.6 x 5.7 x 8.1 in (4.1 x 14.5 x 20.6 cm) / 3 x 8.8 x 11.7 in (7.7 x 22.3 x 29.5 cm)
Shipping Internal / External (HxWxD) 7.9 x 9.4 x 11.4 in (20 x 24 x 29 cm) / 9.4 x 12.2 x 15.4 in (24 x 31 x 39 cm)
Weight
Weight Out of box, Internal 3.2 lb (1.45 kg)
Out of box, External 10.3 lb (4.65 kg)
Shipping, Internal 5.1 lb (2.3 kg)
Shipping, External 11 lb (5 kg)

Benefits:

  • Low Storage Cost
    LTO provides the lowest cost per GB of any medium
  • Business Efficiency
    Manage less data, reduce downtime and speed up applications
  • Ease of Use
    Simplify data migration with LTFS
  • Long-Term Archiving
    30-year archival life
  • Security
    Protect your data from unauthorized access
  • Superior Warranty
    3-year Advance Replacement Service Warranty*

* Availability dependent on location

Documentation:

Download the Tandberg LTO-5 Half Height Tape Drive Datasheet (PDF).

Tandberg LTO Tape Drives
Tandberg LTO-5 Half Height Tape Drive
Tandberg LTO-5 HH - Internal bare drive, black, SAS
#3518-LTO
List Price: $1,599.00
Our Price: $1,338.00
Tandberg LTO-5 HH - Internal drive kit, black, SAS
#3519-LTO
List Price: $1,599.00
Our Price: $1,338.00
Tandberg LTO-5 HH - External drive kit, black, SAS
#3520-LTO
List Price: $1,679.00
Our Price: $1,429.00
Tandberg LTO-5 HH - External bare drive, black, FC
#3530-LTO
List Price: $1,999.00
Our Price: $1,690.00
Tandberg 1U Rackmount SAS
Tandberg 1U Rackmount SAS, supports up to 2 LTO HH SAS drives.
#3512-LTO
List Price: $649.00
Our Price: $529.00
